| Chemical System |
LFP + Gr |
| Rated Capacity |
314 Ah |
| Rated Voltage |
3.2 V |
| Rated Energy |
1004.8 Wh |
| Cell Weight |
5.56 ± 0.15 kg |
| Mass Energy Density |
180.7 Wh/kg |
| Cell Volume |
2.55 L (without terminal) |
| Volume Energy Density |
394.0 Wh/L |
| Alternating Current Resistance |
≤ 0.23 mΩ |
| Charging Temperature |
0 ~ 55 ℃ |
| Discharging Temperature |
-30 ~ 55 ℃ |
| Storage Tempertature |
-40 ~ 60 ℃ |
| Product Certification |
GB/T36276, UL1973, UL1642, IEC62619, UN38.3 |
| Dimension |
H: 207.20 ± 0.50 mm L:174.70 ± 0.50 mm T: 71.57 ± 0.50 mm |
